PERFORMANCE
Recommended amplifier power 20 ­ 200 Watts
Continuous power handling 100 Watts RMS
Peak power handling 400 watt
Sensitivity 93 dB (2.83 Volts @1 metre)
Nominal impedance 8 Ohms
Minimum Impedance 5 ohm
Frequency Response 34 Hz ­ 44 kHz (­6 dB)
Dispersion 90 degrees conical
DRIVE UNITS
Dual Concentric™ high frequency 33 mm (1.3”) aluminium/magnesium alloy dome with edge wound voice
coil
Dual Concentric™ low frequency 254mm (10.00") with paper pulp cone with twin roll impregnated fabric
surround. 52mm (2") edge wound voice coil
CROSSOVER
Frequency 1.3 kHz
Type Bi­wired, hard wired passive, low loss 2nd order low pass, 2nd order high
pass
Adjustment /­ 3dB over 1.3 kHz to 44 kHz shelving
CONSTRUCTION
Enclosure type Dual Distributed Port
Volume 100 L (3.53 cu.ft)
Dimensions 950 x 456 x 336 mm
(37.40 x 17.95 x 13.23”)
Finish Walnut veneer with solid walnut trim and edging. Internally cross braced and
heavily damped.
