Why is the amperage in the graphs so high?
You may be thinking that your CD player only pulls about one amp of current and your amplifier only draws about 12 amps. So how can a test be valid that shows the cord pulling hundreds of amps of current?

Read the DCTD Development white paper. Power supplies only pull current for about 5% to 10% (or less) of the AC duty cycle. During the conduction period, when the cable is actually conducting current, the instantaneous current could be hundreds of amps, but the longer term average is only one to 20 amps, depending upon the device and the load.

Note: If a power supply is drawing 10 amps of current (as measured by a standard current meter), then the peak currents would be 10 to 20 times higher or 100-200 amps of instantaneous current.
